BC Series Hand Held ABS Plastic Enclosures

Hand Case With Battery Compartment and Belt/Pocket Clip Option
This high-impact matt finish black, white or light grey ABS case has an integral PP3 battery compartment with a removable cover and clip-in terminals supplied as standard. Other RAL colours are available on request and the highlighted feature panels make it ideal for personalisation. A pocket/belt clip is supplied for optional use and can easily be fixed to the case with two screws (supplied). The case is held together by two further self tapping screws which are concealed by the battery cover. Four integral location pegs and sockets will hold a PCB in place without any further fixing. The pocket clip BPC1 is available separately.

Hand Case With Battery Compartment and Belt/Pocket Clip Option

This high-impact matt finish black, white or light grey ABS case has an integral PP3 battery compartment with a removable cover and clip-in terminals supplied as standard. Other RAL colours are available on request and the highlighted feature panels make it ideal for personalisation. A pocket/belt clip is supplied for optional use and can easily be fixed to the case with two screws (supplied). The case is held together by two further self tapping screws which are concealed by the battery cover. Four integral location pegs and sockets will hold a PCB in place without any further fixing.
The pocket clip BPC1 is available separately.

Hand Held Case With Battery Compartment and Separate Front Cover
Smart looking case moulded in high-impact black, white or grey ABS with integral PP3 battery compartment accessible by a separate removable cover. The two main halves of the case are held together by two self tapping screws (supplied) with are concealed by the battery cover. The integral bezel and front cover can be removed for ease of manufacture. The overall finish of the case is matt with a polished front panel.

Hand Held Case With Battery Compartment and Separate Front Cover

Smart looking case moulded in high-impact black, white or grey ABS with integral PP3 battery compartment accessible by a separate removable cover. The two main halves of the case are held together by two self tapping screws (supplied) with are concealed by the battery cover. The integral bezel and front cover can be removed for ease of manufacture. The overall finish of the case is matt with a polished front panel.

Hand Held Case With Recessed Membrane Switch Panel and Battery Compartment
Moulded in high impact ABS, this hand held box has a recessed front panel suitable for a membrane type keypad and integral battery compartment accessible by a separate removable cover. The two halves of the case are held together by two concealed screws. A pocket/belt clip is supplied for optional use and can easily be fixed to the case with two screws (supplied). Available in black only as standard with a matt finish. The pocket clip BPC5 is also available separately. Other RAL colours for BC3 and BC5 available on request.

Hand Held Case With Recessed Membrane Switch Panel and Battery Compartment

Moulded in high impact ABS, this hand held box has a recessed front panel suitable for a membrane type keypad and integral battery compartment accessible by a separate removable cover. The two halves of the case are held together by two concealed screws. A pocket/belt clip is supplied for optional use and can easily be fixed to the case with two screws (supplied). Available in black only as standard with a matt finish. The pocket clip BPC5 is also available separately.
Other RAL colours for BC3 and BC5 available on request.

Calculator/Instrument Case With Battery Compartment
A calculator style case moulded in black or white ABS with an overall matt finish. The integral battery compartment with sliding cover will accommodate 2 x PP3 type batteries. Internal PCB pillars are provided in both halves of the case, which are held together by the 4 self tapping screws provided. A small removable panel is provided on the window end of the case to facilitate leads etc, or a window for infra-red remote control applications.

Calculator/Instrument Case With Battery Compartment

A calculator style case moulded in black or white ABS with an overall matt finish. The integral battery compartment with sliding cover will accommodate 2 x PP3 type batteries. Internal PCB pillars are provided in both halves of the case, which are held together by the 4 self tapping screws provided. A small removable panel is provided on the window end of the case to facilitate leads etc, or a window for infra-red remote control applications.

Product Resources
View Product Data Sheet View Customisation Options

Share This Product

BCL Plastic Enclosures
KGA Enclosures Ltd are full authorised distributors of the BCL Plastic Enclosures product range. The entire range is available from KGA Enclosures Ltd at great competitive price's and with full customisation options on all applicable products. To purchase any product or for more information on any product, simply call (+44) 01535 636856 or E-Mail: sales@kgaenclosures.com, where we will be happy to assist you. View the BCL Plastic Enclosures Range View the BCL Plastic Enclosures Price List

BCL Plastic Enclosures

KGA Enclosures Ltd are full authorised distributors of the BCL Plastic Enclosures product range. The entire range is available from KGA Enclosures Ltd at great competitive price's and with full customisation options on all applicable products.

To purchase any product or for more information on any product, simply call (+44) 01535 636856 or E-Mail: sales@kgaenclosures.com, where we will be happy to assist you.

View the BCL Plastic Enclosures Range
View the BCL Plastic Enclosures Price List

BC Series - BCL Plastic Enclosures - KGA Enclosures Ltd

Product Options

Part No	Colour	Length	Width	Depth	1+	10+	50+	More
Hand Held Case With Battery Compartment and Belt Pocket Clip Option
BC2	Black	103mm	62mm	23mm	£4.69	£4.49	£4.30	More....
BC2LG	Light Grey	103mm	62mm	23mm	£4.73	£4.52	£4.33	More....
BC2W	White	103mm	62mm	23mm	£4.73	£4.52	£4.33	More....
Hand Held Case With Battery Compartment and Separate Front Cover
BC3	Black	118mm	66mm	33mm	£2.84	£2.71	£2.60	More....
BC3G	Grey	118mm	66mm	33mm	£2.98	£2.85	£2.73	More....
BC3W	White	118mm	66mm	33mm	£2.98	£2.85	£2.73	More....
Hand Held Case With Recessed Membrane Switch Panel and Battery Compartment
BC5	Black	92mm	63mm	24mm	£2.47	£2.37	£2.27	More....
Calculator / Instrument Case With Battery Compartment
BC4	Black	154mm	81mm	37.5mm	£4.04	£3.86	£3.70	More....
BC4W	White	154mm	81mm	37.5mm	£4.07	£3.90	£3.73	More....

Product Accessories

Protective Rubber Feet

Part No	Colour	Contents	Diameter	Height	1+	10+	25+	More
1421T2	Black	Pack of 24	12.7mm0.50"	3.5mm0.14"	£4.18	£3.85	£3.77	More....
1421T2CL	Clear	Pack of 24	12.7mm0.50"	3.5mm0.14"	£3.04	£2.80	£2.74	More....
1421T2GY	Grey	Pack of 24	12.7mm0.50"	3.5mm0.14"	£4.47	£4.11	£4.02	More....
More Information.....

BCL Enclosures - Customisation Services

Customising Enclosures

BCL Enclosures can machine, drill, punch and generally customise any of there enclosures to suit your individual requirements. BCL Enclosures can mould most of there cases in different materials and offers over 200 RAL colour combinations

Low cost.
Quick service.
One stop sourcing.
High quality and accuracy.
Large volume production runs a specialty.
