Hammond Manufacturing Electrical Enclosures - 1414 N4 AL Series - AE - Junction Boxes

1414 N4 AL Series - Type 4X Aluminium Junction Box

Lift-Off Cover With Clamps

Product Application:

Designed for use as instrument enclosures, electric, hydraulic or pneumatic control housings, electrical junction boxes or terminal wiring enclosures.
Provides protection where equipment may be hosed down or otherwise be very wet, or in specific applications where corrosion is a problem.

Product Construction:

Formed from 0.08" Type 5052 H-32 aluminium.
Smooth, continuously welded seams without knockouts, cutouts or holes.
Welded brackets provide for enclosure mounting.
Cover is secured with easily operated aluminium clamps.
Seamless poured-in place gasket.
All models larger than 4" x 4" include a removable 14 gauge inner panel.
Tapped studs are provided for mounting inner panels.
A bonding stud is provided on the door and a grounding stud is provided in the enclosure.

Product Finish:

Cover and enclosure are natural unfinished aluminium.
Removable inner panel is finished in white powder coating.

Product Standards:

UL 508A Type 4, 4X, 12 and 13.
CSA Type 4, 4X, 12 and 13.
Complies with:
- NEMA Type 4, 4X, 12 and 13.
- IEC 60529, IP66.

How To Order

To order any product or confirm lead times for delivery, please email sales@kgaenclosures.com and include the following:

Company / Contact Name
Full Delivery Address
Contact Telephone Number
E-Mail Address
Confirmation of Part Number and Quantities Required

Or call 01535 636856. We aim to answer all E-Mail inquiries as quickly as possible.

Hammond Manufacturing Electrical Enclosures

KGA Enclosures Ltd are full authorised distributors of the Hammond Manufacturing Electrical Enclosures product range. This entire range is available from KGA Enclosures Ltd at great competitive pricing and with full customisation options on all applicable products.

To purchase any product or for more information on any product offered, simply call (+44) 01535 636856 or E-Mail: sales@kgaenclosures.com, where we will be happy to assist you.

View the Hammond Manufacturing Electrical Enclosures Range
View the Hammond Manufacturing Electrical Enclosures Price List

Or view the related product ranges from Hammond Manufacturing, which are all available from KGA Enclosures Ltd. Including the:

Hammond Manufacturing Enclosures Range
Hammond Manufacturing Power Distribution Range
Hammond Manufacturing Rack Systems Range
Hammond Manufacturing Transformers Range
Ritec Plastic Enclosures Range

Customisation Options

What makes KGA Enclosures Ltd different from most other larger distributors is that we offer full customisation's services on all enclosures and accessories. All customisation work is undertaken by the relevant supplier, (some small projects are done utilizing outside contractors) at their own manufacturing facilities. These services include milling or punching of hole and slots into the enclosure or end plates for cables, connectors, switches etc. Printing and silk screening services allows for the additional of text, logo's and graphics onto both the enclosure and end plates, to allow the end user to easily identify the product as well as giving the final product a more elegant finish. Full customisation services - Click here for more information on full customisation services.

Share This Product

1414 N4 AL Series - Hammond Manufacturing Electrical Enclosures at KGA Enclosures Ltd

View Product Data Sheet
Product Options

Part No	Product Information	1+	10+	25+	50+	More
1414N4ALA	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
1414N4ALC	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
1414N4ALE	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
1414N4ALG	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
1414N4ALI	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
1414N4ALK	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
1414N4ALM6	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
1414N4ALM8	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
1414N4ALO10	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
1414N4ALO6	Please Click Link For More Information	P.O.A.	P.O.A.	P.O.A.	P.O.A.	More....
For pricing confirmation and stock availability please contact us

Hammond Manufacturing - Customisation Services

Modified Electronic Enclosures

Almost every enclosure will need some kind of modification to be useful. In house modifications can be tedious, over complicated and a distraction from your main core business. A third party shop can add time and expense. Let us help you to deliver quality products made to your exact specifications.

Hammond Manufacturing Customisation Services

Why choose Hammond Manufacturing to modify your enclosure

Hammond Manufacturing offers a wide selection and massive inventory of enclosures ready to be modified.
Typically the minimum order quantity is 25 pieces. This can vary depending on product and service required. Please note KGA Enclosures does not add on any charges.
Hammond has an experience enclosure modification team and two dedicated modification facilities in North America and the United Kingdom. They are knowledgeable, available and capable.
Hammond Manufacturing helps eliminate scrap and design errors with approval drawings to confirm correct interpretation of your deign required. Many orders will also include a fast delivery of sample enclosures for your inspection. These steps ensure that your assembly fits perfectly before heading into the mass production stage.

Popular modification services offered:

Holes
Cutouts
Tapping and countersinking.
Pressed-in hardware (Studs, Standoffs)
Silk screening
UV Printing
Special colours
Special length extrusions
Pre-Installed accessories
Available services vary by product
